LD20D
FEATURES
SUPERIOR ENGINE PERFORMANCE
The LD20D engine boasts a rated power of 154 kW, exceeding the industry standard by 10%, ensuring robust power output and optimal operational efficiency.
THE POWER’S IN YOUR HANDS
It is equipped with the luxurious cabin, integrating a high-capacity air conditioning system for enhanced comfort and featuring noise levels that are notably lower than industry averages.
BUILT TO LAST LONGER
Adopting a pivot-type chassis, the vehicle employs modularized powertrain components designed for prolonged service life and ease of maintenance, effortlessly tackling harsh working conditions.
SPECIFICATIONS
Attachments
| Blade Capacity | 4.5 m³ |
| Blade Lift Height | 1,100 mm |
| Blade Cutting Depth | 510 mm |
| Ground Pressure | 55.8 kPa |
| Engine Displacement | 8.9 L |
| Track Shoe Width | 510 mm |
| Number of Rollers (Per Side) | 6 |
| Number of Idlers (Per Side) | 2 |
| Number of Track Shoes (Per Side) | 39 |
| 1st Gear Speed (Forward) | 3.6 km/h |
| 2nd Gear Speed (Forward) | 6.6 km/h |
| 3rd Gear Speed (Forward) | 10.6 km/h |
| 1st Gear Speed (Reverse) | 4.3 km/h |
| 2nd Gear Speed (Reverse) | 7.8 km/h |
| 3rd Gear Speed (Reverse) | 12.6km/h |
Base
| Operating Weight | 17,500 kg |
| Engine Power | 154 kW |
