820TE
FEATURES
World-leading, high-performance
World-leading, high-performance lithium iron phosphate battery;Electric transmission improves transmission efficiency, reduces noise for smooth shifting and operative comfort
Fully electric fixed & variable hydraulics
Fully electric fixed & variable hydraulics deliver better efficiency and reduce energy consumption
Intelligent energy recovery system
Intelligent energy recovery system re-charges the battery to minimize energy consumption
Temperature-controlled electric
Temperature-controlled electric fan has independent control for better energy efficiency;IP67-rated wiring harness, integrated battery is safe and reliable
SPECIFICATIONS
Base
| Operating Weight | 6,600 kg |
| Bucket Capacity | 1.2 m³ |
| Rated load capacity | 2,000 kg |
| Rated Storage Energy | 70.5 kwh |
| Peak Power | 60 kw |
| Standard Breakout Force | 61 kN |
| Standard Dump Clearance | 2,618 mm |
| Fastest Total Cycle Time | 9.8 S |
| Wheelbase | 2,150 mm |
| Transport L*W*H | 5833×2060×2515mm |
