870H
FEATURES
High Performance & Maximum Efficiency
Customized engine, well-matched power-train for strong power output, low fuel consumption;Ground-level servicing, cost-saving routine maintenance.
Advanced & Highly Efficient Hydraulics
Advanced and highly efficient hydraulics deliver fluid on demand without overflow loss to save energy, while offer smooth shift.
High Reliability & Operator Comfort
Heavy-duty wet axle, robust frame structure and dependable components provide high reliability.Pressurized FOPS/ROPS cab, ergonomically design, 309°panoramic visibility and three-stage vibration reduction give the operator a safe and comfortable work environment
SPECIFICATIONS
Base
| Operating Weight | 23,294 kg |
| Bucket Capacity | 4.5 m³ |
| Rated power | 190 kW (255 hp / 258 ps) @ 2,200 rpm |
| Rated Load Capacity | 7,000 kg |
| Hydraulic cycle time | 9.5 s |
| Bucket Breakout Force | 200 kN |
| Tipping load-full turn | 17,166 kg |
| Dump clearance, full height discharge | 3,105 mm |
| Dump reach, full height discharge | 1,320 mm |
| Length with bucket down | 8,849 mm |
| Model | Cummins QSL9.3 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged ﹠ air-to-air intercooled |
GALLERY
