906F

FEATURES

High Performance and Optimal Efficiency in One System

This unit features a fully pressurized and sealed cab, providing comfort along with excellent all-around visibility. It is powered by an environmentally efficient powertrain that maximizes torque output, delivering greater breakout force at lower engine speeds for improved efficiency. The load sensing hydraulic system and auto idle technology further enhance operational efficiency, while the use of world-class components ensures quality, reliability, and easy parts availability.

SPECIFICATIONS

Base

Operating Weight 5,600 kg
Rated Power 35.9 kW (48 hp/49 ps) @ 2000 rpm
Bucket Capacity 0.21 m³

Engine

Model Yanmar 4TNV94L-ZCWCLY
Emission Tier 4 / Stage IV

Hydraulic System

System Maximum Flow 136 L/min
System Pressure 25 MPa

Performance

Arm Digging Force 31 kN
Bucket Digging Force 41 kN

Transport Dimension

Shipping Length 5,900 mm
Shipping Width 2,160 mm
Shipping Height 2,580 mm
Track Shoe Width (STD) 400 mm / 600 mm
