920EES
FEATURES
THE POWER TO MOVE MORE
Powered by a super-efficient, high power output, low emissions Cummins engine and benefiting from advanced hydraulics the 920EES delivers impressive digging performance no matter how tough the terrain. Loading cycle times are faster too thanks to the combination of faster swing speed, perfectly matched arm and bucket.
EASY ON THE OPERATOR
Tough, repetitive tasks like breaking and lifting can lead to operator fatigue and reduced productivity. We keep the operator fresh and alert with a light, responsive hydraulic control joystick. This smart technology ensures that the operator moves the maximum amount of material with the minimum of effort.
REACHING NEW HEIGHTS
With superb traction, stability, and agility the 920EES is perfectly suited to hill locations with steep gradients. In these locations the operator needs confidence in the machine and the 920EES delivers.
EXTRA PERFORMANCE MADE EASY
The 920EES comes complete with an Extra Valve already connected to the Main Control Valve making it even easier to get more productivity from your machine. This Extra Valve makes it easy to add a wide range of attachments such as, hydraulic breakers, shears and grapples to increase your versatility.
SPECIFICATIONS
Base
| Operating Weight | 20,500 kg |
| Rated Power | 124 kW (166 hp / 169 ps) @ 2,050 rpm |
| Bucket Capacity | 0.93 m³ |
Engine
| Model | Cummins QSB7 |
| Emission | Cummins Ⅲ |
Hydraulic System
| System Maximum Flow | 2×224 L/min |
| System Pressure | 34.3 MPa |
Performance
| Arm Digging Force | 105 kN |
| Bucket Digging Force | 135 kN |
Transport Dimension
| Shipping Length | 9,580 mm |
| Shipping Width | 3,000 mm |
| Shipping Height | 3,050 mm |
| Track Shoe Width (STD) | 800 mm |
